1795705 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a panel?
  The recommended torque is 0.6 Nm to 1.2 Nm, depending on the specific application and panel material. It's essential to consult the installation instructions and follow the recommended torque to ensure a secure connection.
• Can I use this connector in a high-vibration environment?
  Yes, the 1795705 connector is designed to withstand vibrations and shocks. It meets the requirements of IEC 61373 Category 2, which means it can operate in environments with vibrations up to 15 g (147 m/s²) and shocks up to 30 g (294 m/s²). However, it's crucial to ensure proper installation and secure fastening to maintain the connector's integrity.
• Is the connector suitable for outdoor use or exposure to harsh environmental conditions?
  The 1795705 connector has a protection rating of IP67, which means it can withstand temporary immersion in water up to 1 meter for 30 minutes. It's also designed to operate in temperatures ranging from -40°C to 100°C. However, it's essential to consider additional protection measures, such as sealing or conformal coating, for extended outdoor use or exposure to harsh environmental conditions.
• Can I use this connector with a different wire gauge or type than recommended?
  While it's technically possible to use a different wire gauge or type, it's not recommended. The 1795705 connector is designed to work with specific wire gauges and types, as specified in the datasheet. Using a different wire gauge or type may compromise the connector's performance, reliability, and safety. It's essential to follow the recommended specifications to ensure a secure and reliable connection.
• How do I ensure proper wire stripping and termination when using this connector?
  To ensure proper wire stripping and termination, follow the recommended wire stripping length and termination procedures outlined in the datasheet or installation instructions. It's essential to use the correct wire stripping tool and to strip the wire to the correct length to prevent damage to the connector or wire. Additionally, ensure that the wire is properly seated and terminated within the connector to prevent electrical issues or failures.
