1814511 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a PCB?
  The recommended torque is 0.4 Nm to 0.6 Nm, as specified in the Phoenix Contact application notes.
• Can I use this connector in a high-vibration environment?
  Yes, the 1814511 connector is designed to withstand vibrations up to 10 g according to IEC 60068-2-6, making it suitable for use in high-vibration applications.
• Is the connector suitable for use in harsh environments, such as those with high humidity or extreme temperatures?
  Yes, the 1814511 connector is designed to operate in temperatures ranging from -40°C to 125°C and can withstand humidity up to 95% RH, making it suitable for use in harsh environments.
• Can I use this connector with wire sizes other than the recommended AWG 20-24?
  While the datasheet recommends AWG 20-24, the connector can accommodate wire sizes from AWG 18 to AWG 26, but the user should verify the wire's compatibility and ensure proper termination.
• Are there any specific PCB layout considerations I should be aware of when using this connector?
  Yes, Phoenix Contact recommends a minimum PCB thickness of 1.6 mm and a keep-out zone of 2 mm around the connector to ensure proper assembly and prevent damage to the PCB.
