1828757 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a PCB?
  The recommended torque is 0.5 Nm to 1.5 Nm, depending on the specific application and PCB material. It's essential to consult the Phoenix Contact application notes for more detailed guidance.
• Can I use this connector in a high-vibration environment?
  Yes, the 1828757 connector is designed to withstand vibrations up to 10 g according to IEC 60068-2-6. However, it's crucial to ensure proper mounting and screwing to prevent damage or disconnection.
• Is this connector suitable for outdoor or harsh environmental applications?
  The 1828757 connector has a IP20 rating, which means it's protected against solid objects larger than 12 mm, but not against water or moisture. For outdoor or harsh environmental applications, consider using connectors with higher IP ratings or additional protection measures.
• Can I use this connector with wire sizes other than the recommended AWG 24-18?
  While the datasheet recommends AWG 24-18 wire sizes, it's possible to use other wire sizes with proper termination and strain relief. However, this may affect the connector's performance and reliability. Consult Phoenix Contact's application notes or contact their technical support for guidance.
• Are there any specific PCB layout considerations for this connector?
  Yes, Phoenix Contact provides PCB layout recommendations in their application notes, including guidelines for pad size, spacing, and solder mask clearance. Following these guidelines ensures reliable connection and prevents damage to the connector or PCB.
