1861959 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector to the PCB?
  The recommended torque is 0.5 Nm to 1.5 Nm, depending on the specific application and PCB material.
• Can I use this connector in high-vibration environments?
  Yes, the 1861959 connector is designed to withstand vibrations up to 10 g according to IEC 60068-2-6. However, it's recommended to perform additional testing for specific applications.
• Is the connector suitable for use in humid or wet environments?
  The 1861959 connector has a IP20 rating, which means it's protected against solid objects > 12 mm, but not against water or moisture. For humid or wet environments, consider using a connector with a higher IP rating or additional sealing measures.
• Can I use this connector for high-current applications?
  The 1861959 connector is rated for up to 12 A per pin. For higher current applications, consider using a connector with a higher current rating or consulting with a Phoenix Contact representative for custom solutions.
• Are there any specific PCB layout recommendations for this connector?
  Yes, Phoenix Contact recommends a minimum PCB thickness of 1.6 mm and a keep-out zone of 2 mm around the connector to ensure proper assembly and reliability.
