1869350 - Phoenix Contact

1869350 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a PCB?
  The recommended torque is 0.5 Nm to 1.5 Nm, depending on the specific application and PCB material. It's essential to follow the manufacturer's guidelines to avoid damaging the connector or PCB.
• Can I use this connector in high-vibration or high-shock applications?
  Yes, the 1869350 connector is designed to withstand vibrations and shocks. However, it's crucial to ensure proper mounting and screwing to prevent damage. Phoenix Contact recommends following the IEC 61373 standard for vibration and shock testing.
• Is the connector suitable for use in harsh environments, such as high temperatures or humidities?
  The 1869350 connector is rated for operating temperatures between -40°C and 125°C, and can withstand humidities up to 95% RH. However, it's essential to consider the specific environmental conditions of your application and consult with Phoenix Contact or a qualified engineer if you have concerns.
• Can I use this connector with wire sizes other than the recommended AWG 20-24?
  While the connector is designed for AWG 20-24 wires, it's possible to use smaller or larger wires with proper wire preparation and strain relief. However, this may affect the connector's performance and reliability. Consult with Phoenix Contact or a qualified engineer for guidance on wire size compatibility.
• Are there any specific PCB layout considerations I should be aware of when using this connector?
  Yes, it's essential to follow Phoenix Contact's recommended PCB layout guidelines to ensure proper connector mating and to prevent damage to the PCB or connector. This includes maintaining a minimum clearance of 1.5 mm around the connector and avoiding vias or through-holes under the connector.
