19022C2U0 - TE Connectivity

19022C2U0 Details

• Manufacturer Part Number:

  19022C2U0

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  10.1 mm

• Body Height:

  11.5 mm

• Body Length or Diameter:

  20.5 mm

• Coil Power:

  500 mW

• Coil Resistance:

  1152 Ω

• Coil Voltage(DC)-Max:

  28.8 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  2A@125VAC

• Contact Current(AC)-Max:

  2 A

• Contact Current(DC)-Max:

  2 A

• Contact (DC) Max Rating R Load:

  2A@125VDC

• Contact Resistance:

  50 mΩ

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  125 V

• Contact/Output Supply Type:

  AC/DC

• End Contact Material:

  Silver

• End Contact Plating:

  GOLD

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Number of Terminals:

  8

• Operate Time:

  7 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  20.5mm x 10.1mm x 11.5mm

• Reference Standard:

  CSA; UL

• Relay Action:

  LATCHED

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Release Time:

  3 ms

• Sealing:

  PLASTIC SEALED

• Terminal Length:

  0.003500127000254001 inch

• Termination Type:

  SOLDER
