193-10MSR - CTS

193-10MSR Details

• Manufacturer Part Number:

  193-10MSR

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Factory Lead Time:

  4 Weeks

• Manufacturer:

  CTS Corporation

• YTEOL:

  6.8

• Actuator Length:

  0.045 inch

• Actuator Type:

  PIANO TYPE

• Additional Feature:

  SHIP AT OFF POSITION

• Body Breadth:

  10.41 mm

• Body Height:

  9.12 mm

• Body Length or Diameter:

  27.58 mm

• Center Contact Plating:

  GOLD

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  .1A@50VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  50 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  7000 Cycle(s)

• End Contact Plating:

  GOLD

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  THERMOPLASTIC

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Switch Sections:

  10

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TAPE AND REEL

• Sealing:

  BOTTOM SEALED

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  PIANO DIP SWITCH

• Termination Type:

  SOLDER
