1953758 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a panel?
  The recommended torque is 0.6 Nm to 1.2 Nm, depending on the specific application and panel material. It's essential to consult the installation instructions and follow the recommended torque to ensure a secure connection.
• Can I use this connector in a high-vibration environment?
  Yes, the 1953758 connector is designed to withstand vibrations and shocks. It meets the requirements of IEC 61373 Category 2, which means it can operate in environments with vibrations up to 15 g (IEC 61373-1) and shocks up to 30 g (IEC 61373-2). However, it's crucial to ensure proper installation and secure fastening to maintain the connector's integrity.
• Is the connector suitable for outdoor use or exposure to harsh environmental conditions?
  The 1953758 connector has a protection rating of IP67, which means it can withstand temporary immersion in water (up to 1 meter for 30 minutes) and is protected against dust ingress. However, it's not designed for continuous outdoor use or exposure to extreme temperatures, chemicals, or UV radiation. If you need a connector for outdoor use, consider using a connector with a higher protection rating, such as IP69K.
• Can I use this connector with a different wire gauge or type?
  The 1953758 connector is designed for use with wires with a gauge range of 0.5 mm² to 2.5 mm² (AWG 20 to AWG 14). While it may be possible to use it with other wire gauges or types, it's essential to consult the datasheet and verify the connector's compatibility with your specific wire requirements. Using an incompatible wire may compromise the connector's performance and reliability.
• How do I ensure proper wire termination and strain relief?
  To ensure proper wire termination and strain relief, follow the recommended wire stripping length and termination procedure outlined in the datasheet. Use the correct wire termination tool and ensure the wire is securely fastened to the connector. Additionally, use a strain relief method, such as a cable tie or clamp, to prevent wire damage and ensure the connector remains securely attached to the panel.
