19S103-400L5 - Rosenberger

19S103-400L5 Details

• Manufacturer Part Number:

  19S103-400L5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Rosenberger

• Additional Feature:

  STANDARD: MIL-STD-202; CAPTIVE CENTER CONTACT

• Body Breadth:

  0.236 inch

• Body Depth:

  0.161 inch

• Body Length:

  0.236 inch

• Body/Shell Style:

  PLUG

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF SMP CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Finish Termination:

  Gold (Au)

• Contact Gender:

  MALE

• Contact Material:

  NOT APPLICABLE

• Contact Resistance:

  6 mΩ

• Contact Style:

  COAX

• Coupling Type:

  SNAP

• DIN Conformance:

  NO

• Durability:

  500 Cycles

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Force-Max:

  44.9248 N

• Insertion Loss:

  0.26 dB

• Insulation Resistance:

  5000000000 Ω

• Insulator Material:

  LIQUID CRYSTAL POLYMER/POLYETHERETHERKETONE/POLYTETRAFLUORO ETHYLENE

• JESD-609 Code:

  e4

• MIL Conformance:

  YES

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Frequency-Max:

  26.5 GHz

• Operating Temperature-Max:

  155 °C

• Operating Temperature-Min:

  -65 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Rated Current (Signal):

  1.2 A

• Terminal Length:

  0.098 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.22

• Withdrawl Force-Min:

  8.896 N
