1ED3890MC12MXUMA1 - Infineon

Description: Gate Drivers ISOLATED DRIVER

Download 1ED3890MC12MXUMA1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
1ED3890MC12MXUMA1 - Infineon PCB footprint - Small Outline Packages - Small Outline Packages - PG-DSO-16_2022
click to zoom
3D Models
1ED3890MC12MXUMA1 - Infineon  - 3D model - Small Outline Packages - PG-DSO-16_2022
click to zoom

1ED3890MC12MXUMA1 Details

  • Manufacturer Part Number:

    1ED3890MC12MXUMA1

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Germany, Indonesia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    20 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    8

  • High Side Driver:

    YES

  • Input Characteristics:

    SCHMITT TRIGGER

  • Interface IC Type:

    BUFFER OR INVERTER BASED IGBT/MOSFET DRIVER

  • JESD-30 Code:

    R-PDSO-G16

  • JESD-609 Code:

    e3

  • Length:

    7.5 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Peak Current Limit-Nom:

    11 A

  • Output Polarity:

    TRUE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SSOP

  • Package Equivalence Code:

    SSOP16,.40

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, SHRINK PITCH

  • Seated Height-Max:

    2.65 mm

  • Supply Current-Max:

    5 mA

  • Supply Voltage-Max:

    5.5 V

  • Supply Voltage-Min:

    3 V

  • Supply Voltage-Nom:

    3.3 V

  • Supply Voltage1-Max:

    25 V

  • Supply Voltage1-Min:

    13 V

  • Supply Voltage1-Nom:

    15 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Turn-off Time:

    0.262 µs

  • Turn-on Time:

    0.27 µs

  • Width:

    6.4 mm

1ED3890MC12MXUMA1 Frequently Asked Questions (FAQs)

  • Infineon provides a recommended PCB layout in their application note AN2013-01, which includes guidelines for thermal vias, copper pours, and component placement to ensure optimal thermal performance.
  • Infineon provides EMC guidelines in their application note AN2014-01, which includes recommendations for PCB layout, component selection, and shielding to minimize electromagnetic interference.
  • Infineon recommends soldering conditions of 260°C for 10 seconds, with a peak temperature of 265°C. Refer to the Infineon soldering guide for more information.
  • Infineon recommends storing the device in an ESD-protective package, handling the device with ESD-protective equipment, and following the ESD handling guidelines outlined in the Infineon application note AN2015-01.
  • Infineon performs a range of reliability and qualification tests, including temperature cycling, humidity testing, and electrical stress testing, to ensure the device meets industry standards for reliability and performance.
