1N5817M-13 - Diodes Incorporated

1N5817M-13 Details

• Manufacturer Part Number:

  1N5817M-13

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  MELF

• Package Description:

  GLASS, MELF-2

• Pin Count:

  2

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  0

• Additional Feature:

  HIGH RELIABILITY

• Application:

  GENERAL PURPOSE

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• JESD-30 Code:

  O-LELF-R2

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Output Current-Max:

  1 A

• Package Body Material:

  GLASS

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  20 V

• Surface Mount:

  YES

• Technology:

  SCHOTTKY

• Terminal Form:

  WRAP AROUND

• Terminal Position:

  END
