1N5818RL - STMicroelectronics

1N5818RL Details

• Manufacturer Part Number:

  1N5818RL

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DO-41

• Package Description:

  PLASTIC PACKAGE-2

• Pin Count:

  2

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Additional Feature:

  FREE WHEELING DIODE

• Application:

  GENERAL PURPOSE

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  0.5 V

• JEDEC-95 Code:

  DO-41

• JESD-30 Code:

  O-PALF-W2

• JESD-609 Code:

  e3

• Non-rep Pk Forward Current-Max:

  25 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Output Current-Max:

  1 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Packing Method:

  TR

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  30 V

• Reverse Current-Max:

  500 µA

• Reverse Test Voltage:

  30 V

• Surface Mount:

  NO

• Technology:

  SCHOTTKY

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL
