1N6761-1 - Microsemi Corporation

1N6761-1 Details

• Manufacturer Part Number:

  1N6761-1

• Part Life Cycle Code:

  Transferred

• Package Description:

  HERMETIC SEALED, GLASS PACKAGE-2

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  Microsemi Corporation (now Microchip)

• Additional Feature:

  HIGH RELIABILITY

• Application:

  GENERAL PURPOSE

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  0.69 V

• JEDEC-95 Code:

  DO-41

• JESD-30 Code:

  O-LALF-W2

• JESD-609 Code:

  e0

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Output Current-Max:

  1 A

• Package Body Material:

  GLASS

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Rep Pk Reverse Voltage-Max:

  100 V

• Surface Mount:

  NO

• Technology:

  SCHOTTKY

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL
