2-1393763-8 - TE Connectivity

2-1393763-8 Details

• Manufacturer Part Number:

  2-1393763-8

• Brand Name:

  CII

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  7 mm

• Body Height:

  7.5 mm

• Body Length or Diameter:

  19.3 mm

• Coil Current(DC)-Max:

  0.024 A

• Coil Operate Voltage(DC):

  8.4 V

• Coil Power:

  140 mW

• Coil Release Voltage(DC):

  1.8 V

• Coil Resistance:

  500 Ω

• Coil Voltage(AC)-Max:

  28 V

• Coil Voltage(DC)-Max:

  28 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  .25A@175VAC

• Contact Current(AC)-Max:

  1.2 A

• Contact Current(DC)-Max:

  1.2 A

• Contact (DC) Max Rating R Load:

  .25A@175VDC

• Contact Voltage(AC)-Max:

  175 V

• Contact Voltage(DC)-Max:

  24 V

• Contact/Output Supply Type:

  AC/DC

• Dielectric Strength Between Coil and Contacts:

  1500 Vrms

• Dielectric Strength Between Open Contacts:

  200 Vrms

• Electrical Life:

  50000000 Cycle(s)

• End Contact Material:

  RUTHENIUM

• Insulation Resistance:

  1000000000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  1.1 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  19.3mm x 6.4mm x 5.7mm

• Reference Standard:

  UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A

• Relay Function:

  SPDT

• Relay Type:

  DRY REED RELAY

• Release Time:

  1.6 ms

• Sealing:

  IP67

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  1.8 g
