2000-1-1-20-00-BK - CNC Tech

2000-1-1-20-00-BK Details

• Manufacturer Part Number:

  2000-1-1-20-00-BK

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  CnC Tech LLC

• Board Mounting Option:

  LOCATING POSTS

• Body Breadth:

  0.262 inch

• Body Depth:

  0.478 inch

• Body Length:

  0.591 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  HDMI CONNECTOR

• Contact Gender:

  FEMALE

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  30 mΩ

• Contact Style:

  TELCOM, MODULAR

• Dielectric Withstanding Voltage:

  300VAC V

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  PLASTIC

• Mixed Contacts:

  NO

• Mounting Option 1:

  MOUNTING FLANGE

• Mounting Option 2:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  2

• Number of Ports:

  1

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  0.75 mm

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  0.5 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  COPPER ALLOY/STEEL

• Terminal Length:

  0.073 inch

• Terminal Pitch:

  1 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  19

• UL Flammability Code:

  94V-0
