20IMX4-03-8 - Bel Power Solutions

20IMX4-03-8 Details

• Manufacturer Part Number:

  20IMX4-03-8

• Pbfree Code:

  No

• Part Life Cycle Code:

  Transferred

• Package Description:

  8.5 MM, DIP-24

• ECCN Code:

  EAR99

• Manufacturer:

  Bel Power Solutions

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE; TUV; UL

• Efficiency (Main Output):

  79%

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  8.4 V

• Input Voltage-Nom:

  20 V

• JESD-30 Code:

  R-XDMA-P7

• JESD-609 Code:

  e0

• Length:

  33 mm

• Line Regulation-Max:

  1%

• Load Regulation-Max:

  3.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  7

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.9 A

• Output Voltage-Max:

  3.33 V

• Output Voltage-Min:

  3.27 V

• Output Voltage-Nom:

  3.3 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  3 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.5 s

• Width:

  20 mm
