2121950010 - Molex

Description: Sentrality 8.00mm Top-entry, Height Above Board 5.17mm, Surface Mount Socket Assembly with +/-1.00mm Misalignment Capability, Tape and Reel

Download 2121950010 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
2121950010 - Molex - PCB symbol
click to zoom
PCB Footprints
2121950010 - Molex PCB footprint - Other - Other - 2121950010
click to zoom
3D Models
2121950010 - Molex - 3D model - Other - 2121950010
click to zoom

2121950010 Details

  • Manufacturer Part Number:

    2121950010

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Mainland China, Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.90.40.00

  • Manufacturer:

    Molex

  • Additional Feature:

    MATERIAL: COPPER ALLOY; FINISH: GOLD

  • Rated Current:

    200 A

  • Rated Voltage:

    600 V

  • Safety Approval:

    UL

  • Terminal and Terminal Block Type:

    PCB TERMINAL

2121950010 Frequently Asked Questions (FAQs)

  • The recommended mating sequence for the 2121950010 connector is to mate the guide pins first, followed by the signal pins. This ensures proper alignment and prevents damage to the connector.
  • Yes, the 2121950010 connector is designed to withstand high-vibration environments. However, it's essential to follow the recommended torque specifications for the screw locks to ensure secure mating.
  • The maximum cable diameter that can be used with the 2121950010 connector is 5.5mm. Using a cable with a larger diameter may compromise the connector's performance and reliability.
  • The 2121950010 connector is designed for indoor use. If you need to use it outdoors, you should consider adding additional protection, such as a waterproof seal or conformal coating, to ensure its reliability in harsh environments.
  • While it's possible to use a different wire gauge, it's not recommended. Using a wire gauge that's not specified in the datasheet may affect the connector's performance, reliability, and durability.
