2170806-1 - TE Connectivity

Description: QSFP28/56, Cage Assembly, Signal, Operating Temperature Range -40 – 85 °C [-40 – 185 °F], Data Rate (Max) 28 Gb/s, 2 Ports

Download 2170806-1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
2170806-1 - TE Connectivity - PCB symbol
click to zoom
PCB Footprints
2170806-1 - TE Connectivity PCB footprint - Other - Other - 2170806-1-4
click to zoom
3D Models
2170806-1 - TE Connectivity - 3D model - Other - 2170806-1-4
click to zoom

2170806-1 Details

  • Manufacturer Part Number:

    2170806-1

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Factory Lead Time:

    18 Weeks, 1 Day

  • Manufacturer:

    TE Connectivity

  • Design Use:

    SIGNAL

  • Material:

    NICKEL SILVER ALLOY

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Terminal Type:

    COMPLIANT FIT

  • Wire Gauge:

    0 AWG
