2171760001 - Molex

2171760001 Details

• Manufacturer Part Number:

  2171760001

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Molex

• YTEOL:

  6.85

• Board Mounting Option:

  PEG

• Body Breadth:

  0.191 inch

• Body Depth:

  0.329 inch

• Body Length:

  0.419 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  USB CONNECTOR

• Contact Gender:

  FEMALE

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  50 mΩ

• Contact Style:

  USB2.0 C

• Dielectric Withstanding Voltage:

  141VAC V

• Durability:

  10000 Cycles

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  PLASTIC

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  1

• Number of Ports:

  1

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• Plating Thickness:

  1u inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  1.25 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  STAINLESS STEEL

• Terminal Pitch:

  1.02 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  6

• UL Flammability Code:

  94V-0
