219-9MST - CTS

219-9MST Details

• Manufacturer Part Number:

  219-9MST

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Factory Lead Time:

  4 Weeks

• Manufacturer:

  CTS Corporation

• YTEOL:

  7.2

• Actuator Length:

  0.01 inch

• Actuator Material:

  POLYETHYLENE

• Actuator Type:

  MEDIUM

• Additional Feature:

  APPROVAL: UL

• Body Breadth:

  6.7 mm

• Body Height:

  4.05 mm

• Body Length or Diameter:

  24.33 mm

• Center Contact Material:

  BERYLLIUM COPPER

• Center Contact Plating:

  GOLD

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  0.1A@20VDC

• Contact Function:

  ON-OFF

• Contact Resistance:

  0.025 mΩ

• Contact Voltage(DC)-Max:

  20 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  2000 Cycle(s)

• End Contact Material:

  BERYLLIUM COPPER

• End Contact Plating:

  GOLD

• Housing Material:

  POLYETHYLENE

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  POLYETHYLENE

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Switch Sections:

  9

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Packing Method:

  TUBE

• Sealing:

  BOTTOM SEALED; TOP TAPE SEALED

• Solderability:

  WAVE

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Termination Type:

  SOLDER
