220-2600-00-0602 - 3M

220-2600-00-0602 Details

• Manufacturer Part Number:

  220-2600-00-0602

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Factory Lead Time:

  13 Weeks

• Manufacturer:

  3M Interconnect

• YTEOL:

  6.78

• Additional Feature:

  STANDARD: UL 94V-0

• Body Breadth:

  0.402 inch

• Body Depth:

  0.409 inch

• Body Length:

  2.77 inch

• Contact Finish Mating:

  GOLD (30) OVER NICKEL (50)

• Contact Finish Termination:

  GOLD OVER NICKEL

• Contact Material:

  BERYLLIUM COPPER

• Contact Style:

  BELLOWED TYPE

• Current Rating:

  1 A

• Device Socket Type:

  IC SOCKET

• Device Type Used On:

  ZIP20

• Dielectric Withstanding Voltage:

  1400VAC V

• Housing Material:

  GLASS FILLED POLYSULFONE

• Insulation Resistance:

  1000000000 Ω

• JESD-609 Code:

  e4

• Mating Contact Pitch:

  0.1 inch

• Mounting Style:

  STRAIGHT

• Number of Contacts:

  20

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• PCB Contact Pattern:

  RECTANGULAR

• Terminal Pitch:

  2.54 mm

• Termination Type:

  SOLDER
