2200HT-821-H-RC - Bourns

2200HT-821-H-RC Details

• Manufacturer Part Number:

  2200HT-821-H-RC

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• Country Of Origin:

  Tunisia

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  25 Weeks

• Manufacturer:

  Bourns Inc

• YTEOL:

  7

• Construction:

  Hortizontal Mount

• DC Resistance:

  0.44 Ω

• Inductance-Nom (L):

  820 µH

• Inductor Application:

  HIGH CURRENT INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e1

• Lead Diameter:

  0.5588 mm

• Lead Spacing:

  23.114 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  200 °C

• Operating Temperature-Min:

  -55 °C

• Package Diameter:

  24.13 mm

• Package Length:

  13.97 mm

• Package Style:

  Toroidal

• Rated Current-Max:

  2 A

• Shape/Size Description:

  CYLINDRICAL PACKAGE

• Shielded:

  YES

• Surface Mount:

  NO

• Terminal Finish:

  TIN SILVER COPPER

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.001 MHz

• Tolerance:

  15%
