2201789 - Phoenix Contact

2201789 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector to the PCB?
  The recommended torque is 0.5 Nm to 1.5 Nm, depending on the specific application and PCB material.
• Can I use this connector in a high-vibration environment?
  Yes, the 2201789 connector is designed to withstand vibrations up to 10 g according to IEC 60068-2-6. However, it's recommended to perform additional testing for specific vibration profiles.
• Is the connector suitable for use in humid or wet environments?
  The 2201789 connector has a IP20 rating, which means it's protected against solid objects > 12 mm, but not against water or moisture. For humid or wet environments, consider using a connector with a higher IP rating or applying additional sealing measures.
• Can I use this connector with a different wire gauge than recommended?
  While it's technically possible, using a different wire gauge may affect the connector's performance and reliability. It's recommended to stick to the recommended wire gauge range (0.5 mm² to 1.5 mm²) for optimal results.
• How do I ensure proper mating and unmating of the connector?
  To ensure proper mating and unmating, follow the recommended mating and unmating forces (max. 20 N), and ensure the connector is properly aligned and seated. Also, consider using a connector with a mechanical keying system to prevent mis-mating.
