225686-E Frequently Asked Questions (FAQs)

• What is the recommended torque value for the screw terminals?
  The recommended torque value for the screw terminals is 0.5-0.7 Nm (4.4-6.3 in-lbs). It's essential to follow this value to ensure reliable connections and prevent damage to the connector.
• Can I use this connector in high-vibration applications?
  Yes, the 225686-E connector is designed to withstand vibrations up to 10g (IEC 60068-2-6) and is suitable for use in high-vibration environments, such as in industrial or transportation applications.
• Is the connector compatible with wire sizes other than AWG 20-24?
  While the datasheet specifies AWG 20-24 wire sizes, the connector can accommodate a range of wire sizes from AWG 18 to AWG 26. However, it's essential to verify the wire size and insulation diameter to ensure proper fit and connection reliability.
• What is the operating temperature range for this connector?
  The 225686-E connector is rated for operation in temperatures ranging from -40°C to 125°C (-40°F to 257°F), making it suitable for use in a wide range of applications, including industrial, automotive, and aerospace.
• Can I use this connector in harsh environments, such as those with high humidity or exposure to chemicals?
  The 225686-E connector is designed to meet the requirements of IEC 60512-2-1 and IEC 60512-2-2 for connector performance in harsh environments. It can withstand exposure to humidity, salt spray, and certain chemicals, but it's essential to consult the datasheet and TE Connectivity's application notes for specific guidance.
