2291392-6 - TE Connectivity

2291392-6 Details

• Manufacturer Part Number:

  2291392-6

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Factory Lead Time:

  17 Weeks, 2 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  6.76

• Additional Feature:

  VSWR MAX AT 3 GHZ

• Body Breadth:

  0.451 inch

• Body Depth:

  0.827 inch

• Body Length:

  0.298 inch

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF SMB CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  MALE

• Contact Material:

  NOT APPLICABLE

• Contact Resistance:

  40 mΩ

• Contact Style:

  COAX

• Coupling Type:

  SNAP

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  800VAC V

• EMI Shielded:

  YES

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulator Color:

  NUT-BROWN

• Insulator Material:

  GLASS FILLED PCT-POLYESTER

• MIL Conformance:

  NO

• Mains Connector Rating:

  115/230VAC

• Mixed Contacts:

  NO

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Operating Frequency-Max:

  6 GHz

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Polarization Key:

  POLARIZED

• Rated Current (Signal):

  1 A

• Shell Finish:

  TIN

• Shell Material:

  ZINC ALLOY

• Terminal Length:

  0.104 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.5
