2327362-1 - TE Connectivity

Description: Body Features: Heat Sink Style Front End Air Flow | Heat Sink Finish Nickel | Heat Sink Height Class Custom | Heat Sink Height .283 INCH | Heat Sink Height 7.2 MM | Configuration Features: Number of Ports 1 | Port Matrix Configuration 1 x 1 | Number of Rear EONs per Port Column 2 | Dimensions: PCB Thickness (Recommended) 1.57 MM | Electrical Characteristics: Data Rate (Max) 400 GBS | Housing Features: Cage Material Nickel Silver Alloy | Operation/Application: Circuit Application Signal | Pluggable I/O Appli

Download 2327362-1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
2327362-1 - TE Connectivity - PCB symbol
click to zoom
PCB Footprints
2327362-1 - TE Connectivity PCB footprint - Other - Other - 2327362-1-1
click to zoom

2327362-1 Details

  • Manufacturer Part Number:

    2327362-1

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Factory Lead Time:

    14 Weeks, 5 Days

  • Manufacturer:

    TE Connectivity

  • Connector Support Type:

    CONNECTOR ACCESSORY

  • Design Use:

    SIGNAL

  • Material:

    NICKEL SILVER ALLOY

  • Operating Temperature-Max:

    65 °C

  • Operating Temperature-Min:

    -55 °C

  • Terminal Type:

    COMPLIANT FIT

  • Wire Gauge:

    0 AWG

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

2327362-1 Overview

Use the download button to access the 2327362-1 schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like 23273, or try a keyword search, such as Assembly Items
