233-208 - Wago

233-208 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a PCB?
  The recommended torque is 0.5 Nm to 1.5 Nm, depending on the specific application and PCB material.
• Can I use this connector for high-vibration applications?
  Yes, the WAGO 233-208 is designed to withstand vibrations up to 10 g according to IEC 60068-2-6. However, it's essential to ensure proper mounting and screwing to prevent damage.
• Is the connector suitable for use in humid or wet environments?
  The WAGO 233-208 has a IP20 rating, which means it's protected against solid objects larger than 12 mm, but not against water or moisture. For humid or wet environments, consider using a connector with a higher IP rating or applying additional protection measures.
• Can I use this connector for high-temperature applications?
  The WAGO 233-208 is rated for operating temperatures between -40°C and 105°C. However, the maximum temperature rating may vary depending on the specific application and the materials used in the connector and PCB.
• What is the recommended wire size and type for this connector?
  The WAGO 233-208 is designed for use with wires ranging from 0.5 mm² to 2.5 mm² (AWG 20 to AWG 14). It's recommended to use wires with a temperature rating of at least 105°C and a insulation material compatible with the connector's plastic housing.
