2349217-1 Frequently Asked Questions (FAQs)

• What is the recommended torque for the screw terminals?
  The recommended torque for the screw terminals is 0.5-0.7 Nm (4.4-6.3 in-lbs). This information can be found in the TE Connectivity application notes or by contacting their technical support.
• Can I use this connector in a high-vibration environment?
  Yes, the 2349217-1 connector is designed to withstand vibrations up to 10G (10 Hz to 2000 Hz) according to IEC 60068-2-6. However, it's recommended to consult with TE Connectivity's technical support for specific application requirements.
• Is this connector suitable for outdoor use?
  The 2349217-1 connector has a rating of IP67, which means it's protected against dust and temporary immersion in water. However, it's not designed for continuous outdoor exposure. For outdoor use, consider using a connector with a higher IP rating or additional environmental protection.
• What is the maximum operating temperature range for this connector?
  The 2349217-1 connector has an operating temperature range of -40°C to 125°C (-40°F to 257°F). This information can be found in the datasheet, but it's essential to verify the temperature range for specific applications.
• Can I use this connector with a different wire gauge than specified?
  The 2349217-1 connector is designed for use with 24-20 AWG wire. While it may be possible to use a different wire gauge, it's not recommended as it may affect the connector's performance and reliability. Consult with TE Connectivity's technical support for specific wire gauge requirements.
