2350202-1 - TE Connectivity

Description: Configuration Features: Port Matrix Configuration 1 x 3 | Number of Ports 3 | Contact Features: Contact Underplating Material Nickel | Contact Mating Area Plating Material Gold | Contact Current Rating (Max) .5 AMP | PCB Contact Termination Area Plating Material Gold Flash | Dimensions: PCB Thickness (Recommended) 2.25 MM | Electrical Characteristics: Data Rate (Max) 32 GBS | Housing Features: Cage Material Stainless Steel | Industry Standards: UL Flammability Rating UL 94V-0 | Operation/Application: Circui

Download 2350202-1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
2350202-1 - TE Connectivity - PCB symbol
click to zoom
PCB Footprints
2350202-1 - TE Connectivity PCB footprint - Other - Other - 2350202-1-1
click to zoom
3D Models
2350202-1 - TE Connectivity - 3D model - Other - 2350202-1-1
click to zoom

2350202-1 Details

  • Manufacturer Part Number:

    2350202-1

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Manufacturer:

    TE Connectivity

  • Connector Support Type:

    CONNECTOR ACCESSORY

  • Design Use:

    SIGNAL

  • Material:

    STAINLESS STEEL

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -55 °C

  • Rated Current:

    0.5 A

  • Terminal Type:

    COMPLIANT FIT

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

2350202-1 Overview

Use the download button to access the 2350202-1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like 23502, or try a keyword search, such as Assembly Items

About TE Connectivity

TE Connectivity, a global leader in connectivity and sensor solutions, designs and manufactures products that enable a more connected world. Serving a diverse range of industries, including automotive, industrial, medical, aerospace, and telecommunications, TE Connectivity offers a broad portfolio of products such as connectors, sensors, relays, and passive components. The company's innovations help improve the reliability and performance of electronic systems.
