2373-05-000 - Coto Technology

2373-05-000 Details

• Manufacturer Part Number:

  2373-05-000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mexico

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.60

• Manufacturer:

  Coto Technology USA

• YTEOL:

  8

• Body Breadth:

  5.33 mm

• Body Height:

  9.7 mm

• Body Length or Diameter:

  20.57 mm

• Coil Current(DC)-Max:

  0.056 A

• Coil Operate Voltage(DC):

  2.5 V

• Coil Power:

  280 mW

• Coil Release Voltage(DC):

  0.4 V

• Coil Resistance:

  90 Ω

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  0.5A@200VAC

• Contact Current(AC)-Max:

  0.5 A

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Power Rating R Load:

  10W@200VDC

• Contact (DC) Max Rating R Load:

  0.5A@200VDC

• Contact Resistance:

  200 mΩ

• Contact Voltage(AC)-Max:

  200 V

• Contact Voltage(DC)-Max:

  200 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  500000000 Cycle(s)

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  8

• Operate Time:

  0.5 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  20.57mm x 5.33mm x 9.7mm

• Relay Action:

  MBB

• Relay Form:

  3 FORM A

• Relay Function:

  3PST

• Relay Type:

  DRY REED RELAY

• Release Time:

  0.15 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Terminal Length:

  0.0034010668021336042 inch

• Termination Type:

  SOLDER
