26-01-3148 - Molex

26-01-3148 Frequently Asked Questions (FAQs)

• What is the recommended torque for the screw terminals?
  The recommended torque for the screw terminals is 0.5-1.5 Nm (4.4-13.3 in-lbs).
• Can I use this connector for high-voltage applications?
  No, the 26-01-3148 is rated for a maximum voltage of 250V AC/DC. For high-voltage applications, consider using a different connector with a higher voltage rating.
• Is this connector suitable for outdoor or harsh environment use?
  The 26-01-3148 has a IP20 rating, which means it provides some protection against solid objects, but it's not designed for outdoor or harsh environment use. For such applications, consider using a connector with a higher IP rating, such as IP67 or IP68.
• Can I use this connector with wire sizes other than 26-20 AWG?
  While the 26-01-3148 is designed for 26-20 AWG wire, it can accommodate smaller wire sizes (e.g., 22 AWG) with some adjustments. However, using larger wire sizes (e.g., 18 AWG) may not be possible due to the connector's design constraints.
• Are there any specific wire stripping requirements for this connector?
  Yes, Molex recommends stripping the wire insulation to a length of 3.5-4.5 mm (0.14-0.18 in) to ensure proper connection and prevent damage to the connector.
