29K102-400L5 - Rosenberger

29K102-400L5 Details

• Manufacturer Part Number:

  29K102-400L5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Hungary

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Rosenberger

• YTEOL:

  7.75

• Body Depth:

  0.248 inch

• Body Diameter:

  0.197 inch

• Body/Shell Style:

  JACK

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF MCX CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Finish Termination:

  Gold (Au)

• Contact Gender:

  FEMALE

• Contact Material:

  NOT APPLICABLE

• Contact Resistance:

  5 mΩ

• Contact Style:

  COAX

• Coupling Type:

  SNAP

• DIN Conformance:

  NO

• Durability:

  500 Cycles

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Force-Max:

  25.3536 N

• Insertion Loss:

  0.12 dB

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  POLYTETRAFLUOROETHYLENE

• JESD-609 Code:

  e4

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Frequency-Max:

  6 GHz

• Operating Temperature-Max:

  155 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Terminal Length:

  0.146 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.2

• Withdrawl Force-Min:

  8.0064 N
