Infineon provides a dedicated application note (AN2014-03) for PCB layout and thermal management guidelines for the 2ED24427N01FXUMA1. It's essential to follow these guidelines to ensure optimal performance, reliability, and thermal dissipation.
Infineon recommends using a gate driver with a minimum output current of 2A and a voltage rating that matches the IGBT's gate-emitter voltage. The 1EDC Compact and 1EDF Fast gate driver families are suitable options. Additionally, consider the driver's propagation delay, rise/fall times, and input/output impedance when selecting a gate driver.
The 2ED24427N01FXUMA1 has a maximum allowed overcurrent of 2.5 times the nominal current (Ic) for a maximum duration of 10ms. The maximum allowed overvoltage is 1.5 times the nominal voltage (Vce) for a maximum duration of 10ms. Exceeding these limits can lead to device damage or failure.
To ensure EMC, follow Infineon's guidelines for PCB layout, grounding, and shielding. Use a Faraday cage or a metal enclosure to shield the module, and ensure proper decoupling of the power supply. Additionally, consider using EMI filters and common-mode chokes to reduce electromagnetic interference.
Store the 2ED24427N01FXUMA1 in its original packaging, away from direct sunlight, moisture, and extreme temperatures. Handle the module by the edges, avoiding touching the pins or electrical contacts. Use an anti-static wrist strap or mat when handling the module to prevent electrostatic discharge damage.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
2ED24427N01FXUMA1 Overview
Use the download button to access the 2ED24427N01FXUMA1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like 2ED24,
or try a keyword search, such as MOSFET Drivers
