2EZ15 - PANJIT

2EZ15 Details

• Manufacturer Part Number:

  2EZ15

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  DO-15

• Package Description:

  ROHS COMPLIANT, PLASTIC PACKAGE-2

• Pin Count:

  2

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  PanJit Semiconductor

• YTEOL:

  5.65

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  ZENER DIODE

• Dynamic Impedance-Max:

  7 Ω

• JEDEC-95 Code:

  DO-15

• JESD-30 Code:

  O-PALF-W2

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  2 W

• Reference Voltage-Nom:

  15 V

• Surface Mount:

  NO

• Technology:

  ZENER

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL

• Voltage Tol-Max:

  5%

• Working Test Current:

  33.4 mA
