2N5038G - Rochester Electronics

2N5038G Details

• Manufacturer Part Number:

  2N5038G

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  TO-3

• Package Description:

  LEAD FREE, CASE-1-07, TO-3, 2 PIN

• Pin Count:

  2

• Manufacturer Package Code:

  CASE LEAD FREE

• Reach Compliance Code:

  Unknown

• Manufacturer:

  Rochester Electronics LLC

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  20 A

• Collector-Emitter Voltage-Max:

  90 V

• Configuration:

  SINGLE

• DC Current Gain-Min (hFE):

  20

• JEDEC-95 Code:

  TO-204AA

• JESD-30 Code:

  O-MBFM-P2

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  NOT SPECIFIED

• Number of Elements:

  1

• Number of Terminals:

  2

• Package Body Material:

  METAL

• Package Shape:

  ROUND

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  NPN

• Qualification Status:

  COMMERCIAL

• Surface Mount:

  NO

• Terminal Finish:

  MATTE TIN

• Terminal Form:

  PIN/PEG

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  40

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  60 MHz
