2N5294 - Microsemi Corporation

2N5294 Details

• Manufacturer Part Number:

  2N5294

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SFM

• Package Description:

  PLASTIC, TO-220, 3 PIN

• Pin Count:

  3

• ECCN Code:

  EAR99

• Manufacturer:

  Microsemi Corporation (now Microchip)

• YTEOL:

  0

• Collector Current-Max (IC):

  4 A

• Collector-Emitter Voltage-Max:

  70 V

• DC Current Gain-Min (hFE):

  30

• JEDEC-95 Code:

  TO-220

• JESD-30 Code:

  R-PSFM-T3

• JESD-609 Code:

  e0

• Number of Terminals:

  3

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  NPN

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Element Material:

  SILICON
