2SJ312(TO-220SM) - Toshiba

2SJ312(TO-220SM) Details

• Manufacturer Part Number:

  2SJ312(TO-220SM)

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TO-220SM

• Package Description:

  TO-220SM, 3/2 PIN

• Pin Count:

  3

• ECCN Code:

  EAR99

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Case Connection:

  DRAIN

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  60 V

• Drain Current-Max (ID):

  14 A

• Drain-source On Resistance-Max:

  0.12 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  220 pF

• JESD-30 Code:

  R-PSSO-G2

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  P-CHANNEL

• Power Dissipation-Max (Abs):

  40 W

• Pulsed Drain Current-Max (IDM):

  56 A

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  SINGLE

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
