3-1415055-1 - TE Connectivity

3-1415055-1 Details

• Manufacturer Part Number:

  3-1415055-1

• Brand Name:

  CII

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Austria

• ECCN Code:

  EAR99

• Factory Lead Time:

  18 Weeks, 3 Days

• Manufacturer:

  TE Connectivity

• Body Breadth:

  13 mm

• Body Height:

  16.5 mm

• Body Length or Diameter:

  40 mm

• Coil Current(AC)-Max:

  0.033 A

• Coil Current(DC)-Max:

  0.033 A

• Coil Operate Voltage(DC):

  18 V

• Coil Power:

  800 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  720 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  8A@240VAC

• Contact Current(AC)-Max:

  8 A

• Contact Current(DC)-Max:

  8 A

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  400 V

• Dielectric Strength Between Coil and Contacts:

  4000 Vrms

• Dielectric Strength Between Open Contacts:

  1500 Vrms

• End Contact Material:

  SILVER TIN OXIDE

• Input Switching Control Type:

  Random

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  10

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  40mm x 13mm x 16.5mm

• Reference Standard:

  EN; IEC; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  4PST

• Relay Type:

  SAFETY RELAY

• Sealing:

  RT3

• Surface Mount:

  NO

• Terminal Length:

  0.0032994665989331978 inch

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  30 g
