3205100012 - Meder

3205100012 Details

• Manufacturer Part Number:

  3205100012

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Standex-Meder Electronics

• Body Breadth:

  6.4 mm

• Body Height:

  5.1 mm

• Body Length or Diameter:

  19.3 mm

• Coil Current(DC)-Max:

  0.01 A

• Coil Operate Voltage(DC):

  3.5 V

• Coil Power:

  50 mW

• Coil Release Voltage(DC):

  0.75 V

• Coil Resistance:

  550 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  0.5A@140VAC

• Contact Current(AC)-Max:

  0.5 A

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Rating R Load:

  .5A@200VDC

• Contact Resistance:

  150 mΩ

• Contact Voltage(AC)-Max:

  140 V

• Contact Voltage(DC)-Max:

  200 V

• Contact/Output Supply Type:

  AC/DC

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  TIN

• Input Switching Control Type:

  Random

• Insulation Resistance:

  10000000000 Ω

• JESD-609 Code:

  e3

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  8

• Operate Time:

  0.5 ms

• Operating Frequency-Max:

  0.01 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Packing Method:

  TUBE

• Physical Dimension:

  19.3mm x 6.4mm x 5.1mm

• Reference Standard:

  UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A

• Relay Function:

  SPST

• Relay Type:

  DRY REED RELAY

• Release Time:

  0.1 ms

• Sealing:

  WATER PROOF

• Surface Mount:

  NO

• Terminal Finish:

  TIN

• Terminal Length:

  0.003048006096012192 inch

• Termination Type:

  SOLDER
