35605-5153-A00PE - 3M

35605-5153-A00PE Details

• Manufacturer Part Number:

  35605-5153-A00PE

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  20 Weeks, 1 Day

• Manufacturer:

  3M Interconnect

• Additional Feature:

  Rated Current(Power): 6A, 3M, POLARIZED

• Board Mounting Option:

  SPLIT BOARD LOCK

• Body Breadth:

  0.366 inch

• Body Depth:

  0.709 inch

• Body Length:

  1 inch

• Body/Shell Style:

  PLUG

• Connector Type:

  RECTANGULAR POWER CONNECTOR

• Contact Arrangement:

  S0P5

• Contact Finish Mating:

  GOLD (20) OVER NICKEL (98)

• Contact Gender:

  MALE

• Contact Material:

  COPPER ALLOY

• Contact Style:

  BLADE PIN-SKT

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  1400VAC V

• Empty Shell:

  NO

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulation Resistance:

  1000000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE

• MIL Conformance:

  NO

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -20 °C

• Option:

  GENERAL PURPOSE

• Plating Thickness:

  20u inch

• Reference Standard:

  UL

• Terminal Length:

  0.102 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  5

• UL Flammability Code:

  94V-0
