3590P-1-203 - Bourns

3590P-1-203 Details

• Manufacturer Part Number:

  3590P-1-203

• Rohs Code:

  No

• Part Life Cycle Code:

  Obsolete

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• HTS Code:

  8533.31.00.00

• Manufacturer:

  Bourns Inc

• YTEOL:

  0

• Actuator Orientation:

  HORIZONTAL

• Actuator Type:

  SHAFT

• Construction:

  Round

• Ganging Number:

  1

• Manufacturer Series:

  3590

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  3

• Number of Turns:

  10

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  1 °C

• Package Diameter:

  22.22 mm

• Package Length:

  18.6 mm

• Package Shape:

  CIRCULAR PACKAGE

• Package Style:

  PCB Mount

• Rated Power Dissipation (P):

  2 W

• Rated Temperature:

  40 °C

• Resistance:

  20000 Ω

• Resistance Law:

  LINEAR

• Resistor Type:

  POTENTIOMETER

• Rotational Angle:

  3600 deg

• Series:

  3590

• Subcategory:

  Variable Resistors

• Surface Mount:

  NO

• Technology:

  WIRE WOUND

• Temperature Coefficient:

  50 ppm/°C

• Terminal Shape:

  FLAT

• Tolerance:

  5%
