Bourns provides a recommended PCB layout and land pattern in their application note AN164, which can be found on their website. It's essential to follow these guidelines to ensure proper soldering and to minimize thermal resistance.
To prevent damage, handle the 3590P-2-502L by the body, avoiding touching the leads or the ceramic element. Use anti-static wrist straps, mats, or packaging to prevent electrostatic discharge (ESD) damage. Avoid bending or flexing the leads, and use a pick-and-place machine or a vacuum pickup tool to handle the component during assembly.
The maximum power rating of the 3590P-2-502L decreases as the temperature increases. According to Bourns' derating curve, the maximum power rating at 125°C is approximately 50% of the rated power at 25°C. Consult the datasheet and application notes for more information on power derating.
The 3590P-2-502L is designed to withstand moderate vibration levels. However, it's essential to evaluate the component's performance in your specific application. Bourns recommends following the IEC 60068-2-6 vibration test standard to ensure the component's reliability in high-vibration environments.
The 3590P-2-502L meets various safety and regulatory standards, including UL, ENEC, and RoHS. However, it's essential to evaluate the component's compliance with your specific application's requirements. Consult with Bourns' technical support and review relevant documentation, such as the datasheet, application notes, and certification reports, to ensure compliance.
