35RAPC7JS - Switchcraft

35RAPC7JS Details

• Manufacturer Part Number:

  35RAPC7JS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Switchcraft Conxall

• YTEOL:

  7

• Additional Feature:

  SHIELDED

• Audio Type:

  STEREO

• Body Breadth:

  1.03 inch

• Body Depth:

  0.64 inch

• Body Length:

  0.59 inch

• Body/Shell Style:

  JACK

• Configuration:

  2X1 HORIZONTAL

• Connector Type:

  3.5MM AUDIO

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  SILVER

• Contact Gender:

  FEMALE

• Contact Material:

  BRASS

• Contact Resistance:

  50 mΩ

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  500V V

• Durability:

  5000 Cycles

• IEC Conformance:

  NO

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• JESD-609 Code:

  e4

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Poles:

  3

• Number of Ports:

  2

• Option:

  GENERAL PURPOSE

• Shell Finish:

  TIN

• Shell Material:

  COPPER ALLOY

• Terminal Length:

  0.11 inch

• Termination Type:

  SOLDER
