36638-0002 - Molex

36638-0002 Details

• Manufacturer Part Number:

  36638-0002

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  India

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Factory Lead Time:

  27 Weeks

• Manufacturer:

  Molex

• YTEOL:

  7

• Additional Feature:

  IP6K7, IP6K8, IP6K9K

• Board Mounting Option:

  PEG

• Body Breadth:

  1.121 inch

• Body Length:

  2.3 inch

• Connector Type:

  BOARD CONNECTOR

• Contact Arrangement:

  S40P8

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Finish Termination:

  Matte Tin (Sn) - with Nickel (Ni) barrier

• Contact Gender:

  MALE

• Contact Material:

  NOT APPLICABLE

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  8 mΩ

• Contact Style:

  SQ PIN-SKT

• Dielectric Withstanding Voltage:

  1000VAC V

• Durability:

  20 Cycles

• Filter Feature:

  NO

• Insertion Force-Max:

  70 N

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  GLASS FILLED POLYBUTYLENE TEREPHTHALATE

• JESD-609 Code:

  e3

• Mating Contact Pitch:

  0.098 inch

• Mating Contact Row Spacing:

  0.165 inch

• Mating Information:

  64320-1311, 64320-3311

• Mixed Contacts:

  YES

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  4

• Number of Rows Loaded:

  4

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• PCB Contact Row Spacing:

  4 mm

• Rated Current (Power):

  12 A

• Rated Current (Signal):

  2.5 A

• Terminal Length:

  3.58 inch

• Terminal Pitch:

  3.5 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  48

• Withdrawl Force-Min:

  70 N
