4-2172082-2 Frequently Asked Questions (FAQs)

• What is the recommended torque value for the screw terminals?
  The recommended torque value for the screw terminals is 0.5-0.7 Nm (4.4-6.3 in-lbs). It's essential to follow this torque specification to ensure reliable connections and prevent damage to the connector.
• Can I use this connector in high-vibration applications?
  Yes, the 4-2172082-2 connector is designed to withstand vibrations and is suitable for use in applications with moderate to high vibration levels. However, it's essential to ensure proper mounting and secure the connector to prevent damage or disconnection.
• Is the connector compatible with wire sizes other than AWG 20-24?
  While the datasheet specifies AWG 20-24 wire sizes, the connector can accommodate smaller wire sizes (e.g., AWG 26-28) with the use of wire adapters or by following TE Connectivity's wire stripping and termination guidelines. However, it's crucial to verify the wire size and termination method to ensure reliable connections.
• Can I use this connector in harsh environmental conditions, such as high temperatures or humidity?
  The 4-2172082-2 connector is designed to operate in a temperature range of -40°C to 105°C (-40°F to 221°F) and can withstand humidity levels up to 95%. However, it's essential to consider the specific environmental conditions of your application and consult with TE Connectivity or a qualified engineer to ensure the connector's suitability.
• Are there any specific PCB layout or design considerations I should be aware of when using this connector?
  Yes, it's essential to follow TE Connectivity's recommended PCB layout guidelines to ensure proper connector mating and to prevent damage to the connector or PCB. Key considerations include maintaining a minimum clearance of 1.5 mm (0.06 in) around the connector, using a solder mask to prevent solder bridging, and ensuring the PCB material can withstand the connector's operating temperatures.
