403-52068-51 - ept

Description: CONNECTOR, HEADER, 68POS, 2ROW, 1.27MM

Download 403-52068-51 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
403-52068-51 - ept - PCB symbol
click to zoom
PCB Footprints
403-52068-51 - ept PCB footprint - Other - Other - 403-52068-51
click to zoom
3D Models
403-52068-51 - ept - 3D model - Other - 403-52068-51
click to zoom

403-52068-51 Details

  • Manufacturer Part Number:

    403-52068-51

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.69.40.40

  • Manufacturer:

    ept Connectors

  • YTEOL:

    9

  • Body Breadth:

    0.224 inch

  • Body Depth:

    0.266 inch

  • Body Length:

    1.9 inch

  • Connector Type:

    BOARD STACKING CONNECTOR

  • Contact Finish Mating:

    NOT APPLICABLE

  • Contact Finish Termination:

    Tin (Sn) - with Nickel (Ni) barrier

  • Contact Gender:

    MALE

  • Contact Material:

    COPPER ALLOY

  • Contact Pattern:

    RECTANGULAR

  • Contact Resistance:

    25 mΩ

  • Contact Style:

    SQ PIN-SKT

  • DIN Conformance:

    NO

  • Durability:

    500 Cycles

  • Filter Feature:

    NO

  • IEC Conformance:

    NO

  • Insulation Resistance:

    10000000000 Ω

  • Insulator Material:

    LIQUID CRYSTAL POLYMER

  • JESD-609 Code:

    e3

  • MIL Conformance:

    NO

  • Mating Contact Pitch:

    0.05 inch

  • Mixed Contacts:

    NO

  • Mounting Option 1:

    LOCKING

  • Mounting Style:

    STRAIGHT

  • Mounting Type:

    BOARD

  • Number Of Connectors:

    ONE

  • Number Of PCB Rows:

    2

  • Number of Rows Loaded:

    2

  • Option:

    GENERAL PURPOSE

  • PCB Contact Pattern:

    RECTANGULAR

  • Rated Current (Signal):

    1.4 A

  • Reference Standard:

    UL

  • Terminal Pitch:

    1.27 mm

  • Termination Type:

    SURFACE MOUNT

  • Total Number of Contacts:

    68

  • UL Flammability Code:

    94V-0

403-52068-51 Frequently Asked Questions (FAQs)

  • The recommended torque value for the screw terminals is 0.5 Nm to 1.5 Nm, depending on the wire size and type. It's essential to consult the manufacturer's application notes or contact their technical support for specific guidance.
  • Yes, the 403-52068-51 connector is designed to withstand vibrations and shocks. However, it's crucial to ensure that the connector is properly secured and mounted to prevent damage or disconnection. Consult the manufacturer's documentation for specific vibration testing and ratings.
  • The 403-52068-51 connector has a IP67 rating, making it suitable for outdoor and harsh environmental applications. However, it's essential to ensure that the connector is properly sealed and protected from moisture, dust, and other environmental factors.
  • The 403-52068-51 connector has an operating temperature range of -40°C to 125°C. However, it's essential to consult the manufacturer's documentation for specific temperature ratings and derating factors.
  • Yes, the 403-52068-51 connector is compatible with aluminum or copper-clad aluminum wires. However, it's essential to ensure that the wire is properly sized and terminated to prevent damage or overheating.
