Bourns provides a recommended PCB layout and land pattern in their application note AN164, which can be found on their website. It's essential to follow these guidelines to ensure proper thermal management and to minimize parasitic inductance.
To select the correct resistor value, consider the maximum current and voltage ratings of the 4114R-1-102, as well as the desired impedance and power rating. You can use online calculators or consult with a Bourns representative to determine the optimal value for your specific application.
The 4114R-1-102 has an operating temperature range of -40°C to +125°C. However, the device's performance and reliability may be affected at extreme temperatures. It's essential to consider the temperature range of your application and potential thermal management requirements.
Yes, the 4114R-1-102 is RoHS (Restriction of Hazardous Substances) and REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) compliant, making it suitable for use in a wide range of applications, including those in the European Union.
Lead times and availability can vary depending on the region, distributor, and quantity required. It's recommended to check with authorized distributors, such as Digi-Key or Mouser, or contact Bourns directly for the most up-to-date information on lead times and availability.
