424-041-522-122 - EDAC

424-041-522-122 Details

• Manufacturer Part Number:

  424-041-522-122

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  EDAC Inc

• YTEOL:

  6.75

• Body Breadth:

  0.531 inch

• Body Depth:

  0.453 inch

• Body Length:

  4.97 inch

• Connector Type:

  CARD EDGE CONNECTOR

• Contact Gender:

  HERMAPHRODITIC

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  10 mΩ

• Dielectric Withstanding Voltage:

  2828VAC V

• Filter Feature:

  NO

• Insertion Force-Max:

  4.45 N

• Insulation Resistance:

  5000000000 Ω

• Insulator Color:

  GREEN

• Insulator Material:

  DIALLYL PHTHALATE

• Mating Contact Pitch:

  0.2 inch

• Mating Contact Row Spacing:

  0.125 inch

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Option 1:

  HOLE 0.128

• Mounting Option 2:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD AND PANEL

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  2

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -65 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  3.17 mm

• Polarization Key:

  POLARIZED KEY

• Rated Current (Power):

  10 A

• Reference Standard:

  UL

• Terminal Length:

  0.186 inch

• Terminal Pitch:

  3.18 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  41

• UL Flammability Code:

  94V-0

• Withdrawl Force-Min:

  0.56 N
