Myrra recommends a 2-layer PCB with a solid ground plane on the bottom layer and a thermal relief pattern around the device's thermal pad to ensure efficient heat dissipation.
Myrra suggests using a secure mounting method, such as screwing or adhesive bonding, and ensuring the PCB is properly secured to the device's housing to minimize mechanical stress.
Although the datasheet specifies a maximum input voltage, Myrra recommends limiting voltage transients to ±10% of the nominal input voltage to prevent damage or malfunction.
Yes, the 44304 can be paralleled to increase output current, but Myrra recommends using a current-sharing scheme, such as a dedicated current-sensing resistor, to ensure balanced current distribution.
Myrra suggests using a systematic approach, including visual inspection, signal integrity analysis, and power-on reset testing, to identify and isolate the root cause of the issue.
