44428-0803 - Molex

44428-0803 Frequently Asked Questions (FAQs)

• What is the recommended torque for the screw terminals?
  The recommended torque for the screw terminals is 0.5-0.7 Nm (4.4-6.3 in-lbs) to ensure secure connections.
• Can I use this connector in high-vibration applications?
  Yes, the 44428-0803 connector is designed to withstand vibrations up to 10G (10 Hz to 2000 Hz) and is suitable for use in high-vibration environments.
• Is this connector suitable for outdoor use?
  The 44428-0803 connector has a rating of IP67, which means it is protected against dust and can withstand immersion in water up to 1m (3.3ft) for 30 minutes. However, it's recommended to use additional sealing or protection for extended outdoor use.
• What is the maximum operating temperature for this connector?
  The 44428-0803 connector has an operating temperature range of -40°C to 105°C (-40°F to 221°F), making it suitable for use in a wide range of applications.
• Can I use this connector with wire sizes other than 18 AWG?
  While the 44428-0803 connector is designed for use with 18 AWG wire, it can accommodate wire sizes from 16 AWG to 20 AWG. However, the wire stripping length and insulation diameter may need to be adjusted accordingly.
